Load frequency control

As the system frequency changes, the bridge circuit is rebalanced by the instrument movement which positions a slide wire used for transmission of a direct voltage.

Load frequency control mcq

The control equipment used consists of the frequency controller only at the larger system and tie-line power controller- recorder at the smaller system. Therefore, the linear incremental relation 8. One thing that is needed to be pointed out here is the fact that in research being done on LFC, at times, some plant limits are omitted. Speed changer: It provides a steady state power output setting for the turbine. In a power system, both active and reactive power demands continually vary with the rising or falling trend. Genetic Algorithm GA : This particular control technique is a depiction of one of the best kind of computer intelligence in power systems. Work is also being done on the enhanced activity of ADRC where area control error responses can be made faster. Power input steam input to turbo-generators or water input to hydro- generators must, therefore, be continuously regulated to match the active power demand; otherwise the machine speed will change with consequent change in frequency, which may be highly undesirable. The frequency control keeps the balance between generation and absorption of real power and thus makes the operation of power station in parallel satisfactory. Different research designs have approved of the GA where it was used along with PI type controllers. Objectives The main purposes have been described in the earlier sections. Tie-line bias control is a modification of the above two types of area control and has been found to work very satisfactorily on power systems where a large number of generators and stations are required to be kept under control. Hydraulic amplifier: It comprises a pilot valve and main piston Low power level pilot valve movement is converted into high power level piston valve movement. Linkage mechanism: ABC is a rigid link pivoted at B and CDE is another rigid link pivoted at This link mechanism provides a movement to the control valve in proportion to change in speed.

In this particular case, no additional information is needed like the precise model information. Complete Block Diagram Representation of Load Frequency Control of an Isolated Power System A complete block diagram representation of an isolated power system comprising turbine, generator, governor and load is easily obtained by combining the block diagrams of individual components, i.

Two area load frequency control problems

Flat tie-line control varies the power input to the prime mover so that the tie-line load is corrected to a predetermined schedule. The main bifurcation between frequency and voltage in power system is on the account of active and reactive power. According to Eq. The governors adjust the input to bring the frequency within permissible limits. One thing that is needed to be pointed out here is the fact that in research being done on LFC, at times, some plant limits are omitted. This is necessitated by the large inertia of the penstock gate which regulates the rate of water input to the turbine. This is the most widely used method on large interconnections. This method is used when a small system and a large system are interconnected through a tie-line. Purpose The major purposes of LFC can be summarized as follows: Maintaining frequency at transient power loads unknown external disturbance Regulation of tie line power exchanger error Tackling ambiguities in the power system model and the variations The role of tie-lines can be understood from the construction of a large power system. The manual controls are sluggish and involve inherent human time lags. An additional feedback loop provides temporary droop compensation to prevent instability. Complete Block Diagram Representation of Load Frequency Control of an Isolated Power System A complete block diagram representation of an isolated power system comprising turbine, generator, governor and load is easily obtained by combining the block diagrams of individual components, i. Tie-line bias control is a modification of the above two types of area control and has been found to work very satisfactorily on power systems where a large number of generators and stations are required to be kept under control. The reverse happens when the speed decreases. This is because the interconnected system has to set their set-points in a different manner.

The extensive use of synchronous clocks establishes a strong requirement for maintaining supply frequency constant in order to have correct timing from such clocks. Let us consider a simple situation in which the speed changer has a fixed setting i.

Existing Load Frequency Control Solutions We have the concept of a decentralized power system where compartmentalization subsystems are created to keep the tie line disturbances in check.

To understand the load frequency control problem, let us consider a single turbo-generator system supplying an isolated load. Did you have enough information?

Load frequency control slideshare

This control of frequency by the action of governors is called the primary control. Owing to the introduction of tie lines, the controller has also got to deal with tie line power exchange error. Thus, the turbine transfer function is characterized by two time constants. Modelling of a hydro-turbine regulating system is beyond the scope of this book. In such cases, when the controllers are being designed, all approximations have to be included in the parameters. Active disturbance rejection control ADRC : This particular control technique has been modified over time and is a popular one in terms of practicality. Typically the time constant Tt lies in the range 0. Because of this, the practicality of controllers could be hindered on a large scale usage. The control equipment consists of load frequency controller and tie-line load recorder-controller. Conclusion In this post we have reviewed various aspects of LFC and how they are relevant in a power system. In this manner, its activity is very directed and efficient against the uncertainty or any external disturbance in the system.

By the use of area requirement, proportional load control, the equipment is able to call for changes at the several generating stations such that they each, in effect, supply the load of their respective areas, thereby causing a minimum of power flow over the tie feeders from one station to another.

The dynamic response is largely influenced by two factors, i entrained steam between the inlet steam valve and first stage of the turbine, ii the storage action in the reheater which causes the output of the low pressure stage to lag behind that of the high pressure stage.

Fly ball speed governor: This is the heart of the system which senses the change in speed frequency. The control equipment used consists of the frequency controller only at the larger system and tie-line power controller- recorder at the smaller system.

load frequency control with controller theory

Purpose The major purposes of LFC can be summarized as follows: Maintaining frequency at transient power loads unknown external disturbance Regulation of tie line power exchanger error Tackling ambiguities in the power system model and the variations The role of tie-lines can be understood from the construction of a large power system.

By this method, the load swings are shared by both stations A and B and therefore, the swings on each station and on the line would be reduced.

Difference between automatic generation control and load frequency control

The reverse happens for upward movement of speed changer. In this manner, its activity is very directed and efficient against the uncertainty or any external disturbance in the system. Tie-line bias control is a modification of the above two types of area control and has been found to work very satisfactorily on power systems where a large number of generators and stations are required to be kept under control. This is where the application of genetic algorithms comes in. Existing Load Frequency Control Solutions We have the concept of a decentralized power system where compartmentalization subsystems are created to keep the tie line disturbances in check. The large system maintains the system frequency constant while the small system is controlled to keep the tie-line power constant. Thus, the turbine transfer function is characterized by two time constants. In a power system, both active and reactive power demands continually vary with the rising or falling trend. We can now focus at the objective of: Maintaining the frequency Keeping the tie line power exchange in sync The objectives can be understood better in terms of solutions that have been explained next. The main bifurcation between frequency and voltage in power system is on the account of active and reactive power.
